Muffle Furnace - WMF-12H

Brand	Wiggens
Category	Laboratory Equipment
Subcategory

Contact Sales

Chamber volume: 12L
Temperature range: RT+15-1600?

Description

Operation and Display
> Intelligent navigation operation, can be directly access into the settings
> The main interface shows setting temperature, actual temperature, output power, historical data, alarm records and other information, convenient to enter the destination menu directly

Program
> Integrated temperature program, 10×30 steps
> Display the temperature curve in real-time

Data storage and connection
> Data storage, transfer, and invocation
> Experiment data and alarm information can be transfer by USB stick
> Communication interface included RS232, RS485, RJ45, can be remote controlled by PC and SCADA

Safety
> Overheat protection (Electronic and mechanical protection), Overload and leakage protection, Selfdiagnosis
> With password protection to prevent the process of setting parameters are changed
> Standard with passive exhaust port, ensure gas pressure safety
> With high quality thermocouple, ensure accurate temperature control and long service time

Specification

Model		WMF-12H
Chamber volume (L)		12
Heating	Temperature range (?)	RT+15~1600
	Temperature stability (?)	±1.5
	Heating	Heat on three sides
	Temperature control	PID
	Heating capacity (KW)	7
Program		Integrated temperature program, 10×30 steps
Safety device		Overheat, Overload and leakage protection, Self-diagnosis, with password protection
Temperature curve		Display the temperature curve in real-time
Communication interface		RS232, RS485, RJ45, USB-A for data export
Power supply		Aviation connector of the power supply, AC220, 50/60Hz
Dimensions (W×D×H mm)		715×765×1201
Chamber dimensions(W×D×H mm)		200×300×200
Weight (KG)		194
Order No.		W6122012
