Product
Infrared Hot Plate - SLK2-T
Brand Wiggens
Category
Subcategory
Maximum temperature setting with E-sensor [? ]: 300
Description

> Smooth and corrosion resistant ceramic glass top plate
> Excellent transmittance of the infrared light
> Material can resist a thermal shock of up to 700?
> Corrosion-resistant, solid casing which is hermetically sealed
> Fast heating and excellent temperature stability
> Temperature can be externally controlled by the connection of a Pt100 temperature sensor
> Large LCD screen displays the set and actual temperature
> A high-temperature indicator warns the user and prevents burning injuries
> Compressed air connector optionally available for the use of the hotplate in an aggressive environment
> Rod holder can be conveniently used to connect diverse accessories such as a temperature sensor
> Can be connected to an external temperature sensor for direct and precise temperature control

Specifications

Model

SLK2-T

Order No.

W3032392

Maximum temperature setting

550 [? ] / 24 steps

Maximum temperature setting with E-sensor [? ]

300

Safety temperature [? ]

50~600 adjustable

High temperature protection [? ]

10~50 adjustable

Temperature stability with E-sensor [? ]

±1

Heat output [W]

1800

External temperature sensor

Pt100

PID parameter

3 sets

Temperature and Speed display

LCD display

Temperature and Speed setting

Turning knob

Time setting

1~1999min / continuous

Top plate material

Ceramic glass

Top plate dimensions [mm]

280×280

Heating zone [mm]

Ø190

USB interface

Yes

Dimensions W x D x H [mm]

290x450x120

Weight [kg]

4.1

Power supply

220V/50Hz

*Measured with 500ml water at 80 ?
Standard package includes: hot plate, thermocouple sensor PT100-01 with holder and clamp
